Thin Gauge Cut To Length Line

Slide 1
Thin Gauge Cut To Length
Line

Thin Gauge Cut to Length Line efficiently cuts light gauge coils into precise flat sheets with smooth leveling, high accuracy, and minimal waste perfect for lightweight material processing.

Thin-Gauge-Cut-To-Length-Line

Thin Gauge CTL Lines

The LOTOS Thin-Gauge CTL Line is engineered for processing light and delicate metal coils with thicknesses up to 3 mm, delivering precise length cutting with minimal surface stress. Featuring a precision, high speed hydraulic guillotine shear and low-inertia tension control system, this line ensures burr-free sheets with tight length tolerances, even at high throughput speeds. The frame and mechanical structure are optimized for stability while protecting sensitive coil surfaces such as stainless steel and aluminum. Advanced automation with recipe management, line synchronization, and inline inspection enhances efficiency and reduces operator dependency. Compact in design yet highly efficient, the LOTOS Thin  Gauge CTL Line is ideal for service centers and manufacturers handling lightweight, high-quality sheet materials.

Key Features:

  • High speed and precision
  • Ideal for high-volume production
  • Excellent flatness and surface protection
FAQ

1. What is a Thin Gauge Cut to Length Line?

A Thin Gauge Cut to Length Line is a coil processing system designed to uncoil, level, and cut thin steel or aluminum coils into flat sheets of precise dimensions. It is ideal for light-gauge materials, usually ranging from 0.2 mm to 3 mm thickness.

2. Which industries use Thin Gauge Cut to Length Lines?

These lines are widely used in industries such as appliance manufacturing, automotive, construction, roofing, electrical enclosures, and furniture production, where thin and accurate sheets are required.

3. What materials can be processed?

LOTOSSLITTING Thin Gauge CTL lines can handle cold rolled steel, galvanized steel, stainless steel, aluminum, and pre-painted coils, ensuring high-quality surface finish without damage.

4. What are the advantages of LOTOSSLITTING Thin Gauge CTL Line?

  • High-speed cutting with accuracy.

  • Smooth leveling to remove coil set and improve flatness.

  • Automated operation with PLC control for easy handling.

  • Flexible customization for sheet length, width, and stacking systems.

=
