High speed and automatic slitting line
In addition to its speed and precision, the Slitting Line is also incredibly versatile. It can handle a wide range of materials, including metal coils, plastic films, paper rolls, and more. Whether you’re working with thin materials or thick ones, the High-Speed Slitting Line can handle it all with ease. Its adjustable settings and customizable features make it suitable for various industries and applications.
Furthermore, the Slitting machine is designed with user-friendliness in mind. It features a user-friendly interface that allows operators to easily control and monitor the machine’s performance. Its intuitive controls and clear display make it simple for anyone to operate, eliminating the need for extensive training or technical expertise.
Main technical parameters:
Steel coil parameters | Material
| Cold roll and galvanized steel |
Tensile strength | δb≤450Mpa | |
Steel thickness
| 0.2-2.0mm | |
Steel width | 1500（Max） | |
Steel coil I.D | φ480-520 mm | |
Steel coil O.D | φ1600mm（Max） | |
Steel coil weight | 15T（Max） | |
Slitter parameters | knife pivot diameter | Ф200 mm |
Knife pivot material | 40Cr | |
Blades specification | Φ340mmXφ200mmX10mm | |
Blade material | 6CrW2Si | |
Slit parameter | Max slit quantity | 30 pcs (0.3mm) |
Width precision | ≤±0.05mm/2M | |
Other parameters | Power | 380V/50Hz/3Ph |
Line speed | 0-120m/min | |
Capacity | 230 Kw | |
Whole line Dimension | 23m(L)X10m(W) | |
Operator needed | 1 mechanical engineer ,2 common workers | |
Line direction | From right to left(Face to machine) |
